Saturday, June 23, 2012

Solar Imaging Session - June 23, 2012 (Numerous Huge Prominences !!!)

As I arrive to Manila  from my Baguio work trip this morning, I saw the sky was clear and despite still tired from my long travel, I was tempted to setup at our laundry area to try to see how the Sun looks like after almost 40 days of no regular solar imaging session (of course this doesn't include  the May 21 annular solar eclipse as well as June 6th Venus transit whereas I concentrated on the event itself rather than doing my routine solar work.)

I waited till the Sun is visible at our laundry area around past 10:30am, I setup and look through white light and could only see a very small pore AR11509 sunspot group on the disk :(  Switching to Ha wavelength is another story as I could visually see numerous huge prominences visible around the solar limb!  I quickly started imaging as I could see that I have more or less another hour left for me to image before I get obstructed again by our roof :(

The session was worth it and I couldn't and care that I had to haul down my solar setup from 3rd floor to ground floor just to be able to see what old Sol is doing on the days I missed him :) LOL







Thursday, June 14, 2012

June 6, 2012 Venus Transit

Last June 6, 2012, I, together with some members of the Astronomical League of the Philippines (ALP) that comprises the Binondo Venus transit team setup at 27th floor of fellow ALPer Alberto Lao's place at La Granda Mansion. ALP Binondo team comprises me as the team leader with fellow members Alberto Lao, Edgar Ang, Andrew Ian Chan, Berenice Viola Chan, Iah Serna, and new upcoming member Marvy Gulapa. I setup my trusty TV-101 refractor with 2x Televue Big Barlow for negative projection shot of the Sun while a Coronado PST-Ha was setup along side my scope for some Ha imaging along the way. They are both mounted on top of the Vixen GP-DX mount; Edgar brought along his Orion XT6 Newtonian reflector mounted on top of a Celestron CG-5GT mount; Andrew setup his Skywatcher 80ED refractor at prime focus on Vixen GP mount; Albert uses a Sony 500mm f.8 mirror lens while Berenice uses a Canon EF 18-200mm lens. They started to setup before sunrise but the weather was a bit hazy and it was very hard for me to get a good focus even though I was using a Baader density 3.8 solar filter which lets more sunlight through than the traditional density 5.0, I initially has to use clouds near the Sun to get some close focus but I eventually was able to get correct focus before Venus Ingress I started more or less around 6:12:47am with a tiny small clip off of light near the northeast limb of the Sun! Venus transit has begun and I could hear camera clicking all the way specially my good friend Albert Lao, which I could discern his camera 7fps frame bursting like a machine gun firing away :) LOL .  With the haze and clouds, I opted to sacrifice a little on frame rates and use RAW mode to image the Ingress times so I will have some flexibility to process the images later as I'm sure to expect lots of processing to enhance the Sun's limb to brought out the Venus silhouette.  Ingress II was recorded more or less around 6:30:22am.  Due to the haze, black drop effect was also very pronounce after Ingress II as I could see Venus western limb being stretched a bit from the Sun's limb.  Several small group of sunspots were also visible on  the Sun's disk but they are far away from the path of the Venus transit :(

Despite the unusually thick haze, we were able to continue documenting the event. The equatorial mount helped a lot to lessen the burden of trying to center the Sun on the camera screen.  As the transit progresses, clouds and haze continue to hamper us until we reach the greatest transit time more or less around 9:30am!  Greatest transit time refers to the time  when Venus is halfway between Ingress I (First Contact) and Egress IV (4th Contact).  During this time, some commotions over at Edgar's scope as all were looking through his sharp views of the Venus transit and some of us specially Berenice, Andrew and Edgar were also able to use their Iphone to capture the view with very sharp images!

With Venus needing around 7 hours to cross the Sun's disk, all of us were hungry and thirsty as well!  The group would also like to thank fellow ALPer and host Alberto Lao for  treating us for some delicious lunch packs as well as drinks!  Thank you Albert for your generosity ! From then on, it was almost 90% clear all the way till the last view of Venus' disk totally disappeared to the Northwest limb. I also got a call from fellow ALPer Alex Loinaz who was stationed in PAGASA observatory in UP Diliman telling me if I notice Venus motion across the disk was like an E path as it seems he said "Venus is moving back to where it has started!"   Fellow ALPer Berenice also noticed it but I had to explained to them the effect of this unusual effect was caused by the fact that they were observing and imaging the event through an altazimuth mount particularly a photo tripod.  With the Sun  passing meridian, the Sun's orientation would have rotated slightly back and forth during the time it is crossing near the meridian time.  Andrew had to ask his sister Berenice to remove his camera from the tripod and ask here to follow the Sun handheld and the myth is busted :) LOL  Everyone had a good laugh and also the newbies got to learn something new from the veterans of the group :)  The strange E shaped movement of Venus can be eliminated when  one is observing through an equatorial mounted camera or scope.  Below composite image I made of the Venus transit could well help break this myth :)

During this time, our telescopes were almost near zenith and I had to lay down almost on the hot concrete floor just to get some shots as we approach Egress III.  Because the floor has red paint, I had to removed my dearest ALP uniform before I lay on the floor so as not to stain my uniform :) LOL  Despite the heated floor, I persevere and was treated with good shots of the Egress :)  Egress III was recorded more or less around 12:30:12pm.  A small hint of black drop effect can also be seen but not as pronounced as that of the one after Ingress II because of better sky condition, Egress IV was recorded at 12:47:34pm. Also worth mentioning is the fact 5 minutes before Egress starts, our telescope mount were asking for a telescope reversal so as not to let the telescope hit the tripod, but I had to ignore it because no more time to reverse the mount and recenter it again!  So after Egress, I only got a few millimeter left before my camera hits the tripod leg :) LOL  ALPer and Treasurer Andrew Ian Chan fondly call this moment "Near 5th Contact!!!" :) LOL

Overall, it was a  success on the ALP Venus Transit Binondo Team as we were able to capture the entire event from Ingress to Egress! I later heard from fellow ALPer and VP Jett Aguilar who was stationed at his observatory in Marikina was not able to capture Egress because of heavy downpour during that time and only stopped after the end of Egress :(  As for the ALP Luneta team, they lost Ingress because of thick haze as well as  former Miss Philippines Venus Raj's  appearance at the scope of ALPer and PRO Armando Lee hence wasn't able to timed the event  :(  But they were able to record the Egress successfully though.  Overall, I could say the ALP observation and documentation of this rare event is an OVERALL SUCCESS!!!

Below are the Venus transit's composite and individual images of Ingress, Black Drop Effect, Greatest Transit Time and Egress in Chronological order.

Venus Transit Composite Image




Venus Transit Composite Color Image


Ingress I (Ingress II Exterior) Progression


Ingress II (Ingress Interior)


Black Drop Effect After Ingress II (Ingress Interior)


Venus Transit at Greatest Transit Time


Venus Transit in Ha wavelength


Venus Transit in Ha wavelength


Egress III (Egress Interior)


Black Drop Effect During Egress III


Midway Between Egress III and IV (Egress Exterior)


Egress III (Egress Interior)Progression


Egress IV (Egress Exterior)Progression



Egress IV (Egress Exterior)




Below are some activity shots I took during the event.


Me beside my Venus Transit Imaging Setup - Canon EOS 500D on TV-101 refractor with ATK-1HS II webcam on Coronado PST-Ha on GP-DX mount.


I gotta wear Solar Shades !!! Cool!


I'm practically almost lying on the ground to image the Venus Transit at Egress Times


ALPer Andrew Ian Chan and Iah Serna beside Andrew's Skywatcher 80ED refractor on GP mount


ALPer Edgar Ang beside his Orion XT6 Newtonian reflector on Celestron CG5-GT mount.



ALPer Albert Lao beside his Sony A700 on Sony 500mm f/8 mirror lens.


ALPer Berenice Viola Chan beside his Canon EOS 500D on Canon EF 18-200mm lens.


My Venus Transit setup's position after the conclusion of the Venus Transit event!


A few minutes before undergoing "5th Contact!" - Crashing the camera into the Scope Tripod! :) LOL


ALP Venus Transit Binondo Team



SUCCESS !!!






Monday, June 4, 2012

June 4, 2012 Partial Lunar Eclipse

ALPers James Kevin Ty and Alberto Lao went up to the roof deck of Albert Lao's residence which has an access roofdeck at 27th floor. This will also be the area where the ALP Venus Transit Binondo Team will be setting up on June 6, 2012. They started to setup at around 6:10pm and waited for the Moon to appear through some cloud layers in the eastern horizon. Unfortunately, clouds only started to disperse a bit more or less around 7:00pm Philippine Standard Time (PST). Maximum Lunar Eclipse was visible through some thin clouds but started to clear up after 7:08pm. ALP President James Kevin Ty brought along his ultra portable setup in Canon EOS 500D DSLR on Canon EF 100-400mm f.4.5-5.6 IS L lens set at 400mm f.5.6 mounted on top of Kenko Sky Memo-R tracker. ALPer Alberto Lao, on the other hand, uses a Sony Alpha A77 DSLR on 500mm/F8RF mirror lens. They were able to continuously imaging the eclipse till around 8:40pm before they packed up and call it a night!
